Rapid Impact Compaction:

RIC makes possible the consolidation of material up to a depth of 6m using two RIC 9 ton and one RIC12 ton hydraulic hammers. The hydraulic hammers are mounted on mobile 50 ton and bigger caterpillar excavators.

The typical coverage per RIC machine ranges from 800m2 to 1,200m2 calculated at a 5m depth of influence. This equates to an average of 5,000m3 of material treated per day, per RIC machine.

Rapid Impact Compaction is 40 – 60% less expensive and at least 3 times faster than conventional compaction. This holds huge benefits in terms of the project’s critical path programme.

Comparison with Conventional Dynamic Compaction

Dynamic Compactions imparts impact energy to soils or fills through the controlled dropping of a large weight from a specific height.

With conventional DC, the weight is typically 10 to 15 tons, the height is 5 to 15m and the frequency is one to two drops per minute. The BSP Rapid Impact Compactor imparts energy by dropping a 5, 7 or 9 ton weight from a relatively low height (1.2m) at a very much higher rate of 40 to 60 times per minute.

The energy inputs of both systems are directly comparable but the energy transfer of the Compactor is far more effective by virtue of its foot, which stays in contact with the ground during the impacting sequence; this ensures the efficient transfer of energy into the ground.

Divider

Stone Column installation

Installation of rock to a depth of 5m to construct a raft, stiffen the insitu material, relieve pore water pressures during installation; followed by the installation of a layer of geo-grid to minimize and spread differential settlement.

Dynamic Compaction (Deep Compaction and stone column installation)

Consolidation of material (depth range 4m to 10m) using two 60 ton lattice boom cranes which have drop weights of 12 tons and a maximum drop of 18m.

Divider

Piling

The types of piling services we can offer, together with the design of the piles, are as follows.

  • Micro piles,
  • Driven Piles up to Super Heavy,
  • Tubes and profile piles,
  • Rotary Auger Piles,
  • CFA piles.

Sheet piling installation:

We have the following equipment available:

  • Two high frequency sheet piling hammers mounted on 20 ton excavators,
  • one 10PHF PTC Vibro drivers mounted on a 30 ton excavator but can also be mounted on our 60 ton DC cranes,
  • one 10PHF PTC Vibro drivers mounted on a 30 ton excavator but can also be mounted on our 60 ton DC cranes,
  • two Giken SA 100 ton Silent Pilers – Hydraulic (First on the African Continent- See link below for more information).

The advantages of the Giken 100 ton Hydraulic pilers include:

  • No vibration – work can be conducted in close proximity to existing services and structures,
  • piles may be installed where there is limited headroom – sheet piles are welded at each 3m interval,
  • laser guided – sheet piles can be installed on a minimum curvature of 8m radius.

Divider

Excavator mounted hydraulic milling / rotating cutters

The new generation rotation units are tough enough for use with rotary drum cutters for tunneling, trenching and profiling. The rotation units are long-lasting, robust and low-maintenance.

Divider

Lateral Support and ground and rock anchors

Divider

Rotary core drilling for geotechnical investigation and other purposes

Divider

Design and geotechnical consulting services:

The designs for the above geotechnical services are performed by a global renowned Geotechnical Consulting firm. RIC Africa and their consultants will also provide Professional Indemnity insurance for the design and, if required, for work to be performed.

Divider

Quality Assurance (Testing):

(a) Continuous Surface Wave Testing (CSW testing)
RIC Africa utilise the services of Prof Gerhard Heymann to perform Continuous Surface Wave testing (Pre and Post works) to establish the stiffness of the in-situ material created after RIC, dynamic compaction and stone column installations.

The data yielded may then be shared with the client’s civil, structural and geotechnical consultants.

(b) Dynamic Probing Super Heavy (DPSH)
Apart from the CSW testing we, RIC Africa, also provide the service of Dynamic Probe Super heavy (DPSH) to determine N values in sand and gravel in-situ material t depths of 8m.

Divider

Vibration monitoring

The process involves the placing of vibration monitors in predetermined positions to monitor the vibrations generated. The monitors have remote communication abilities.

The type of monitoring can be changed from continues monitoring with pre-set trigger levels for individual events to a Histogram Combo.

Divider

RIC Africa operates throughout South Africa, Namibia and the broader African continent.

To find out more about the professional geotechnical services we provide, please call us on +27 21 975 0933, or click here to e-mail us.
